5.4.2.4 INTERBUS
INTERBUS has been designed as fast sensor / actuator bus for transmitting process data in
industrial environments.
The INTERBUS is a single master system, i.e. all participants of an INTERBUS ring are con-
trolled by one INTERBUS master (controller board).
The INTERBUS uses in principle a ring structure as bus topology.
The signal way of the INTERBUS begins at the controller board and leads through all IN-
TERBUS participants ending at the controller board again.
Further details about INTERBUS communication you will find in online help of ELOP II Fac-
tory.
6 Labeling
6.1.1 Equipment Identification
The equipment is identified and labeled in accordance to the standards, such as DIN 6779.
