7.4.2 Table of Configurations for Digital Outputs
All permissible configurations for digital outputs accepted by ELOP II Factory are listed in
the following table. Additional system signals have no influence on further variations (e.g.
signal DO[xx].LS with reduced voltage). At wrong parameterization an entry "IOA wrong
initial data" is set in the diagnosis. At the same time the parameterization is displayed. With
the following table the error can be located.
Configuration possibilities of digital outputs
Appli-
cation
Channel1
2-pole
Channel2
2-pole
Channel1
LSLB
Channel2
LSLB
common
reference
pole
1-pole 0 0 0 0 0
0 1 0 0 0
0 1 0 1 0
1 0 0 0 0
1 0 1 0 0
1 1 0 0 0
1 1 0 1 0
1 1 1 0 0
2-pole
1 1 1 1 0
1 1 0 1 1
1 1 0 0 1
1 1 1 0 1
3-pole
1 1 1 1 1
Table 20: Configuration possibilities of digital outputs
Explanations for the table:
0 = Option is not set
1 = Option is set
LSLB: short-circuit and line break detection (line monitoring)
