HIMA HIMatrix F1 DI 16 01 Engineering Manual

HI 800 101 HIMatrix Engineering Manual
9 Operating Conditions
The devices were developed in compliance with the requirements of the following standards
for EMC, climate and environment:
IEC/EN 61131-2 Programmable Controllers, Part 2
Equipment Requirement and Tests
IEC/EN 61000-6-2 EMC
Generic Standards, Part 6-2
Immunity for Industrial Environments
IEC/EN 61000-6-4 EMC
Generic Emission Standard
Industrial Environment
For the use of the safety-related HIMatrix controller systems the following common condi-
tions have to be met:
Protection class Protection class II according to IEC/EN 61131-2
Pollution Pollution degree II
Altitude < 2000 m
Enclosure Standard: IP 20
If requested by the relevant application standards (e.g.
EN 60204, EN 954-1), the device must be installed in a
required enclosure (e.g. IP 54).
9.1 Climatic Conditions
The most important tests and limit values for climatic conditions are listed in the following ta-
ble:
IEC/EN 61131-2
Chapter 6.3.4
Climatic Tests
Temperature, ambient: 0...60 °C
(Test limits -10...+70 °C)
Storage Temperature: -40...85 °C
(with battery only -30 °C)
6.3.4.2
Dry heat and cold withstand test:
70 °C / -25 °C, 96 h, EUT power supply unconnected
6.3.4.3
Change of temperature, withstand and immunity test:
-25 °C / 70 °C and 0 °C / 55 °C,
EUT power supply unconnected
6.3.4.4
Cyclic damp heat withstand test:
25 °C / 55 °C, 95 % relative humidity,
EUT power supply unconnected
59 of 61
