HIMA HIMatrix F1 DI 16 01 Engineering Manual

HI 800 101 HIMatrix Engineering Manual
7.4 Line Monitoring at F3 DIO 16/8 01
7.4.1 Parameterization of Line Monitoring at 2-Pole Connection
Note
For all corresponding system signals of line monitoring initial
values have to be set.
Therefore all needed or wanted configurations of system signals
(see
Table 19) must be set first in ELOP II Factory, then the
application program must be compiled and at last the program
must be transferred to the controller.
A change of the settings for the system signals of line monitoring
is not possible during operation!
Signal name Type Description Default
value
DO.LSLB period
WORD
Period in which LSLB monitoring is carried out
in [s], range 1…100 s in steps of 1
-
DO.LSLB time
UINT
Monitoring time for LSLB monitoring in [ms],
range 0…50 ms in steps of 1ms, default: 0 ms
0 ms
DO[01].2-pole
BOOL
Parameterization whether channel1 is used
2-pole
1 = channel is used 2-pole
0 = channel is used 1-pole
0
DO[02].2-pole
BOOL
Parameterization whether channel2 is used
2-pole
1 = channel is used 2-pole
0 = channel is used 1-pole
0
DO[01].LSLB
monitoring
BOOL
Parameterization of the line monitoring
channel1
1 = LSLB monitoring is carried out
0 = LSLB monitoring is not carried out
0
DO[02].LSLB
monitoring
BOOL
Parameterization of the line monitoring
channel2
1 = LSLB monitoring is carried out
0 = LSLB monitoring is not carried out
0
DO[01].+Value
BOOL
Output value for DO channel1 (DO+), 2-pole,
identically to DO- (Value: 0 or 1)
DO[01].-Value
BOOL
Output value for DO channel1 (DO-), 2-pole,
identically to DO+ (Value: 0 or 1)
0
DO[02].+Value
BOOL
Output value for DO channel2 (DO+), 2-pole,
identically to DO- (Value: 0 or 1)
0
DO[02].-Value
BOOL
Output value for DO channel2 (DO-), 2-pole,
identically to DO+ (Value: 0 or 1)
0
DO.Error Code
WORD
Error code of all digital outputs
-
DO[01].+Error
Code
WORD
Error code of digital output DO+ in channel1
-
DO[01].-Error
Code
WORD
Error code of digital output DO- in channel1
-
DO[02].+Error
Code
WORD
Error code of digital output DO+ in channel2
-
DO[02].-Error
Code
WORD
Error code of digital output DO- in channel2
-
51 of 61
