HIMA HIMatrix F1 DI 16 01 Engineering Manual

HI 800 101 HIMatrix Engineering Manual
The following table contains the used switch signals of the example:
Signal name Type Description Initial
value
Remarks
Switch_1_1pulsed
Switch_1_2pulsed
BOOL
BOOL
Value
Value
Switch 1 first and
second contact
Switch_2_1pulsed
Switch_2_2pulsed
BOOL
BOOL
Value
Value
Switch 2 first and
second contact
Switch_1_1_EC
Switch_1_2_EC
BYTE
BYTE
Error code
Error code
Error Codes
Switch 1 first and
second contact
Switch_2_1_EC
Switch_2_2_EC
BYTE
BYTE
Error code
Error code
Error Codes
Switch 2 first and
second contact
Table 15: Switch signals for Line Control
Slot of the modules with pulsed outputs within remote I/O or compact system:
Controller Signal value
DI Pulse Slot
F1 D1 16 01 1
F3 DIO 8/8 01 3
F3 DIO 16/8 01 3
F3 DIO 20/8 01,
F3 DIO 20/8 02
2
F20 2
F30 2
F31 2
Table 16: Slot of module with the pulsed outputs
7.2.2 Configuration for Pulsed Outputs
The pulsed outputs must begin at DO[01] and must be directly sequential:
Outputs Examples for admissible configurations ... ... for non-admissible
DO[01].Value A1 Pulse_ON Pulse_ON Pulse_ON A1
Pulse_ON
DO[02].Value A2 Pulse_ON Pulse_ON Pulse_ON
Pulse_ON Pulse_ON
DO[03].Value A3 Pulse_ON Pulse_ON Pulse_ON
Pulse_ON
A3
DO[04].Value A4 A4 Pulse_ON Pulse_ON
Pulse_ON Pulse_ON
DO[05].Value A5 A5 A5 Pulse_ON
Pulse_ON Pulse_ON
DO[06].Value A6 A6 A6 Pulse_ON A6
Pulse_ON
DO[07].Value A7 A7 A7 A7 A7 A7
DO[08].Value A8 A8 A8 A8 A8 A8
Table 17: Configuration for pulsed outputs
The relevant inputs can be selected as desired, i.e. two sequential pulsed outputs need not
be assigned to two adjacent inputs.
Restriction
Two directly adjacent inputs may not be supplied from the same pulse; this will prevent
crosstalk.
44 of 61
