6.4 Communicating with PC
1
2
3
4
5
6
7
8
9
10
11
付録
索引
139
6.4.3 Downloading Data to Save to PC/
Setting up Instrument on PC
Procedure
1. Move the shutter to reveal the USB ter-
minal.
2. Connect the USB Cable to the USB ter-
minal.
3. Click the [Start] button and choose
[Programs]-[HIOKI]-[3455]-[Data
Analysis Software for 3455 English].
 Operation  See the help function or the user’s
manual of the data analysis software for 3455.
Use a 2-m or shorter USB cable to avoid noise.
Do not connect to the instrument if test leads
are still connected.
Move the shutter.
USB
terminal
