3.4 Measuring Temperature
82
3.4.1 Measurement Procedure
Procedure
1. Move the shutter to reveal the tempera-
ture sensor terminal.
2. Connect the temperature sensor to the
temperature sensor terminal.
3.4 Measuring Temperature
Do not attempt to measure the tempera-
ture of objects carrying a voltage. Doing
so will result in a short-circuit accident or
an electrocution accident.
Temperature sensors may be damaged by
high voltage or static electricity. Do not
expose the temperature sensor to excessive
impact, or allow the cable to be bent, since
malfunction or faulty connection may result.
Move the shutter.
Temperature
sensor terminal
To Next Page
