Function Specications
7.4 Function Specications
(1) E󰀨ective range of battery display
Operation Function for checking the voltage of the internal battery.
Display
Battery voltage Status gauge
10.6 V
±
0.2 V 6
10.2 V
±
0.2 V to 10.6 V
±
0.2 V 5
10.0 V
±
0.2 V to 10.2 V
±
0.2 V 4
9.8 V
±
0.2 V to 10.0 V
±
0.2 V 3
9.5 V
±
0.2 V to 9.8 V
±
0.2 V 2
8.8 V
±
0.2 V to 9.5 V
±
0.2 V 1
Up to 8.8 V
±
0.2 V 0 (battery shape blinks)
Hysteresis: Even if the battery voltage rises, the status gauge will not increase
once it has decreased until the power is turned o󰀨 and on again.
A measurement cannot be taken when the status gauge is 0 (the measured
value will not be displayed).
(2) Live line warning display
Operation Displays the voltage between the + & − terminals and the measurement status
with the warning lamp on the MEASURE key.
This function works for all functions except when o󰀨.
Display
Function Status
Voltage between
terminals
Live line
warning display
Insulation
resistance
PV insulation
resistance
MEASURE key on – Blinks
MEASURE key o󰀨
and during automatic
discharge
30 V DC or more Blinks
MEASURE key
o󰀨 and not during
automatic discharge
30 V AC or more,
+30 V DC or more,
−30 V DC or less
Blinks
Rated DC
measurement
voltage or more,
95 V AC or more*
1
Blinks
(Buzzer
beeping*
2
)
Voltage –
30 V AC or more,
+30 V DC or more,
−30 V DC or less
Blinks
*1. If induction noise is present, the instrument will output the test voltage.
*2. Voltage cannot be generated when the buzzer is beeping.
