Measuring Insulation Resistance
3.3 Measuring Insulation Resistance
DANGER
To avoid an electric shock and a short-circuit, make sure to
observe the following precautions.
1. Check Table 1 before connecting test leads to the instrument.
2. Check to see if the object under measurement is not live or electrically
charged using a high-voltage detector or other similar instrument,
before connecting test leads to it.
Table 1
Check item Result Action
Are the
mark and
MEASURE key lamp o?
O Connect test leads to the
instrument and check 2
above.
If safe to proceed, connect the
test leads to the object under
measurement. Go to Table 2.
Blinking Press the MEASURE key to
stop voltage generation.
Table 2
Check item Result Action
Are the
mark and
MEASURE key lamp blinking?
Not blinking A measurement can be
performed.
Blinking Immediately disconnect the
test leads from the object
under measurement and turn
o power to the object or
discharge the electric charge
using a discharge rod.
To Next Page
