Recording Measurement Data
(Data Memory Function)
The instrument stores measurement data, settings, date, time, temperature, and
humidity in the internal memory.
The data memory function can be used in insulation resistance measurements.
The recorded data is saved even when the power is turned o󰀨.
There are two recording methods. (Combinable)
Manual recording Records the measured value retained on the display.
Logging recording
Records the measured value at each set recording interval.
(Set the recording interval or timer before measurement.)
• Logging recording can be used in insulation resistance measurement and PV
insulation resistance measurement. For insulation diagnosis functions, timer test
can only be used (p. 88).
• The content of a manual record is viewed on the display of the instrument. The
recorded data can also be downloaded to a PC using the DT4900 communications
package (option).
• For logging records, only the last value is viewed on the display of the instrument.
The entire record is viewed on a PC using Sequence Maker.
See: “5.6 Communicating with PC” (p. 79)
• Add memory number to data to record. The memory number serves as the address
in the memory. The recording methods and conguration of memory number are
shown below.
Recording method Memory number
Manual recording
A00 - A99, B00 - B99, C00 - C99, D00 - D99, E00 - E99, F00 - F99,
H00 - H99, J00 - J99, N00 - N99, P00 - P99
(1000 numbers in total)
Logging recording Lr0 - Lr9 (10 numbers in total. Up to 60 minutes of logging per data)
