Specications of the Options
7.5 Specications of the Options
Test leads
(1) Conguration
Model name Color Cable length Weight Remarks
L9850-01 Red
Approx. 3 m (118.11 in.)
Approx. 88 g (3.1 oz.)
L9850-02 Black Approx. 213 g (7.5 oz.) Shielded cable
L9850-03 Blue Approx. 88 g (3.1 oz.)
L9850-11 Red
Approx. 10 m (393.70 in.)
Approx. 240 g (8.5 oz.)
L9850-12 Black Approx. 620 g (21.9 oz.) Shielded cable
L9850-13 Blue Approx. 240 g (8.5 oz.)
(2) General specications
Application Dedicated accessory for the IR5050/IR5051 High Voltage Insulation
Tester
Operating
environment
Indoor use, pollution degree 2, altitude up to 2000 m (6562 ft.)
Operating
temperature and
humidity range
−20
°
C to 50
°
C (−4
°
F to 122
°
F), 80% RH or less (non-condensing))
Storage temperature
and humidity range
−25
°
C to 65
°
C (−13
°
F to 149
°
F), 80% RH or less (non-condensing)
Standards Safety: EN 61010
Maximum rated line-
to-ground voltage
5000 V DC (2 mA) (insulation resistance measurement)
1000 V (Measurement category IV), Anticipated transient overvoltage
12,000 V
2000 V (Measurement category III), Anticipated transient overvoltage
15,000 V
Rated voltage 2000 V AC, 5000 V DC
Rated current 4 A
