Specications of the Options
Test pin set
(1) Conguration
The set is composed of one red pin and one black pin.
Model
name
Color Dimensions Weight Remarks
L9852 Red
and
black
Total length: Approx. 111.5 mm (4.39 in.)
Tip of pin (section with exposed metal):
Approx. 3.7 mm (0.15 in.)
Tip-to-protective nger guard length:
Approx. 55.5 mm (2.19 in.)
Approx.
7 g (0.2 oz.)
Used on the tip
of the L9850
Test Lead.
(2) General specications
Application Accessory dedicated for the IR5050/IR5051 High Voltage Insulation
Tester
Operating
environment
Indoor use, pollution degree 2, altitude up to 2000 m (6562 ft.)
Operating
temperature and
humidity range
−20
°
C to 50
°
C (−4
°
F to 122
°
F), 80% RH or less (non-condensing)
Storage temperature
and humidity range
−25
°
C to 65
°
C (−13
°
F to 149
°
F), 80% RH or less (non-condensing)
Standards Safety: EN 61010
Maximum rated line-
to-ground voltage
5000 V DC (2 mA) (insulation resistance measurement)
1000 V (Measurement category IV), Anticipated transient overvoltage
12,000 V
2000 V (Measurement category III), Anticipated transient overvoltage
15,000 V
Rated voltage 2000 V AC, 5000 V DC
Rated current 4 A
