Specications
7.1 General Specications
Operating
environment
Indoor use, pollution degree 2, altitude up to 2000 m (6562 ft.)
Operating
temperature and
humidity range
−20
°
C to 40
°
C (−4
°
F to 104
°
F), 80% RH or less (non-condensing)
40
°
C to 45
°
C (104
°
F to 113
°
F), 80% RH or less (non-condensing)
45
°
C to 50
°
C (113
°
F to 122
°
F), 80% RH or less (non-condensing)
Storage temperature
and humidity range
−25
°
C to 65
°
C (−13
°
F to 149
°
F), 80% RH or less (non-condensing)
Dust resistance and
water resistance
IP40 (when the protector is attached; excluding terminals section)
IP65 (C0212 Carrying Case) (EN 60529)
The protection rating for the enclosure of this instrument (based on
EN 60529) is IP40 or IP65.
IP40, IP65:
This indicates the degree of protection provided by the enclosure
of the device for use in hazardous locations, entry of solid foreign
objects, and the ingress of water.
IP4X: Protected against access to hazardous parts with wire
measuring 1.0 mm in diameter. The equipment inside the
enclosure is protected against entry by solid foreign objects
larger than 1.0 mm in diameter.
IPX0: The equipment inside the enclosure is not protected against the
harmful e󰀨ects of water.
IP6X: Protected against access to hazardous parts with wire
measuring 1.0 mm in diameter. Dustproof type (Dust shall not
penetrate the enclosure.)
IPX5: The equipment inside the enclosure is protected against the
harmful e󰀨ects of water projected in jets against the enclosure
from any direction.
Standards Safety: EN 61010
EMC: EN 61326
Insulation tester: IEC 61557-1, IEC 61557-2
Power supply Use one of the following.
• LR6 Alkaline battery
×
8
Rated supply voltage: 1.5 V DC
×
8
• HR6 Nickel-metal hydride battery
×
8
Rated supply voltage: 1.2 V DC
×
8
Maximum rated power: 12 VA
E󰀨ective range of battery: 8.8 V
±
0.2 V to 13.6 V
Continuous
operating time
Using LR6 Alkaline battery
×
8 (Reference value at 23
°
C)
Approx. 5 hours (Generating 5 kV, open between + & − terminals,
backlight o󰀨, comparator o󰀨, and Z3210 not installed)
Approx. 4 hours (Generating 5 kV, open between + & − terminals,
backlight o󰀨, comparator o󰀨, Z3210 installed, and
using wireless communications)
Backup battery life Approx. 10 years (Reference value at 23
°
C)
Dimensions Approx. 195W
×
254H
×
89D mm (Approx. 7.7"W
×
10.0"H
×
3.5"D)
