Contents
4 Insulation Diagnosis Functions 59
4.1 TIMER Function (Timer Test) ..........................................59
4.2 PI (Polarization Index) and DAR (Dielectric Absorption
Ratio) Measurement .......................................................61
4.3 SV Measurement (Step Voltage Test) ............................. 63
4.4 Ramp Measurement (Ramp Voltage Test) ...................... 66
4.5 DD Measurement (Dielectric Discharge) ........................68
4.6 Changing Settings for the Insulation Diagnosis
Functions ........................................................................70
5 Other Functions 71
5.1 Comparator Function ......................................................71
5.2 Automatic Power Save Function ..................................... 73
Recovering from the automatic power save state .................... 73
Disabling automatic power save function .................................73
5.3 Wireless Communications Function
(GENNECT Cross) .......................................................... 74
5.4 Excel Direct Input Function (HID Function) .....................76
5.5 Version Upgrade Function .............................................78
5.6 Communicating with PC ..................................................79
5.7 Power On Options List ....................................................82
6 Recording Measurement Data (Data Memory
Function) 85
6.1 Recording Measurement Data ........................................87
Manual recording (recording result of one measurement
session) ....................................................................................87
Logging recording (recording at regular intervals) ................... 88
6.2 Checking Recorded Data ................................................ 90
6.3 Deleting Recorded Data ..................................................92
Deleting data with the selected number ................................... 92
Deleting all data .......................................................................92
7 Specications 93
7.1 General Specications ....................................................93
