3.3 Making Settings from the LR5000 Utility Program
36
Scaling (set as needed)
The following scaling calculation is applied to measured values.
Scaled Result = Raw data (measured value) × A + B × SI prefix (multiplier)
The scaled result is displayed on the logger.
3 Settings on the [Measurement Method] tab
Click the [E
dit] button to display the setting dialog box.
3
See: "What is Scaling?" (p.38)
Enable scaling
Select this check box to enable scaling.
Clicking this tab
changes the setting
options. Make set-
tings on either tab.
(The settings are ap-
plied to the other
tab.)
Specify by example, or Specify by A/B
To Next Page
