Hioki RM3544 - BCD Signal Timing; Panel Load Timing

8.2 Timing Chart
100
BCDm_n signal transition time based on the BCD_LOW signal
Panel Load Timing
BCD Signal Timing
LOAD0 to LOAD3 Panel 1 Panel 2
Panel 1 Panel 2Load processing
Approx. 0.5 s, max
Approx.
10 ms
State
BCD2-0 to BCD5-3
BCD1-0 to BCD1-4
RNG_OUT0 to RNG_OUT3
BCD2-0 to BCD5-3
BCD_LOW
BCDm-n
Upper (OFF)
1 ms, max
Upper (OFF)
1 ms, max
Lower (ON)
