3.3 Connecting Measurement Leads to the Measurement Target
34
Before making measurements, read "Operating Precautions" (p.5) carefully.
Example with L2101
Example with L2102
Example with L2104
3.3 Connecting Measurement Leads to the Mea-
surement Target
(Place leads in contact with target.)
SOURCE A SENSE A SENSE B SOURCE B
The SENSE terminals are placed to the inside of the SOURCE terminals.
