8.4 External I/O Settings
114
You can select whether to hold EOM signal output until the next trigger is input or output a
user-specified pulse width.
Setting EOM Signal
1
Open the Settings Screen.
2
Open the EXT I/O Setting Screen.
3
Select the EOM signal output type.
When using the internal trigger [INT], the EOM pulse width is fixed at 5 ms, regardless of
the settings.
The Settings screen
appears.
Switch the function menu
to P.2/2.
1
2
Move the cursor to the [I/O]
tab with the left and right cur-
sor keys.
2
The EOM signal remains
asserted after end-of-mea-
surement (default)
(to step 5).
The specified pulse is out-
put after end-of-measure-
ment.
Selection
1
To Next Page
