4.4 Correcting Measured Values and Displaying Physical Properties Other than Resistance
54
This function applies a correction to measured values. It can be used to cancel the effects
of the probing position or differences between measuring instruments, or to apply a user-
specified offset as an alternative to zero-adjustment. In addition, units can be specified,
allowing it to be used to convert measured values to physical properties other than resis-
tance (for example, length).
Scaling is performed by means of the following equations:
R
S
= A × R + B
R
S
: Resistance value after scaling
R : Measured value after zero-adjustment and temperature correction
A : Gain coefficient Setting range: 0.2000 × 10
-3
to 1.9999 × 10
3
B : Offset Setting range: 0 to ±1 × 10
9
(maximum resolution: 1 n)
Displayed and sent/received measured values as well as the printer output format vary with
the gain coefficient.
4.4 Correcting Measured Values and Displaying
Physical Properties Other than Resistance
Values (Scaling Function)
1
Open the Settings Screen.
Range
Gain coefficient
(0.2000 to
1.9999)
×10
-3
(0.2000 to
1.9999)
×10
-2
(0.2000 to
1.9999)
×10
-1
(0.2000 to
1.9999)
×1
(0.2000 to
1.9999)
×10
(0.2000 to
1.9999)
×10
2
(0.2000 to
1.9999)
×10
3
30 m 00.000  000.00  0.0000 m 00.000 m 000.00 m 0.0000 00.000
300 m 000.00  0.0000 m 00.000 m 000.00 m 0.0000 00.000 000.00
3  0.0000 m 00.000 m 000.00 m 0.0000 00.000 000.00 0.0000 k
30  00.000 m 000.00 m 0.0000 00.000 000.00 0.0000 k 00.000 k
300  000.00 m 0.0000 00.000 000.00 0.0000 k 00.000 k 000.00 k
3 k 0.0000 00.000 000.00 0.0000 k 00.000 k 000.00 k 0.0000 M
30 k 00.000 000.00 0.0000 k 00.000 k 000.00 k 0.0000 M 00.000 M
300 k 000.00 0.0000 k 00.000 k 000.00 k 0.0000 M 00.000 M 000.00 M
3 M 0.0000 k 00.000 k 000.00 k 0.0000 M 00.000 M 000.00 M 0.0000 G
The Settings screen
appears.
Switch the function menu
to P.2/2.
1
2
