Hirschmann PAT IFLEX5 User Manual

Error Codes
© Hirschmann Rev. I 05/22/17 190154_I.DOC
63
Error Code
Error
Cause
Elimination
E06
Radius range
exceeded or fallen
below angle range
with luffing jib
operation
 Maximum radius as
specified in the load chart
exceeded or fallen below
minimum angle due to
luffing down the luffing jib
too far
 Luff the jib to a radius or
angle specified in the load
chart.
E07
Overload relays
check
 relays = overload active
and CU input 20 = on
 relays = no overload
and CU input 20 = off
 PDB variable invalid
 emergency stop caused
by system software
 check cable to overload
relays and CU input 20
 check relays
 check CU input 20
 reset system
 reset system
E11
Fallen below lower
limit value for
measuring channel
"length main boom"
 Length potentiometer is
defective
 Replace length
potentiometer
 Electronic component in
the measuring channel is
defective
 Replace sensor unit
E12
Fallen below the
lower limit value in
the measuring
channel "pressure
piston side"
 Pressure transducer is
defective.
 Replace pressure
transducer
 Electronic component in
the measuring channel is
defective.
 Replace sensor unit
E13
Fallen below lower
limit value in the
measuring channel
"pressure rod side"
 refer to E12
 refer to E12
E14
Fallen below lower
limit value in
measuring channel
"force"
 Force transducer
defective
 Electronic component in
the measuring channel is
defective.
 Replace force transducer
 Replace sensor unit
E15
Fallen below lower
limit value in
measuring channel
"angle main boom"
 Angle potentiometer
defective
 Replace angle sensor
 Electronic component in
the measuring channel
defective.
 Replace sensor unit
