Hirschmann PowerMICE User Manual

Network Load Control
UM Basic Configuration L3P
Release 7.1 12/2011
8.4 QoS/Priority
179
 Always assign port priority to received data packets
(PowerMICE, MACH 104, MACH 1040 and MACH 4000)
 Always assign port priority to received data packets
 Assigning the traffic class to a DSCP
User Priority Traffic Class
------------- -------------
0 2
1 2
2 0
3 1
4 2
5 2
6 3
7 3
enable Switch to the privileged EXEC mode.
configure Switch to the Configuration mode.
interface 1/1 Switch to the Interface Configuration mode of
interface 1/1.
no classofservice trust
vlan priority 1
Assign the “no trust” mode to the interface.
Set the port priority to 1.
exit Switch to the Configuration mode.
exit Switch to the privileged EXEC mode.
show classofservice trust
1/1
Display the trust mode on interface 1/1.
Class of Service Trust Mode: Untrusted
Untrusted Traffic Class: 4
 Select the
QOS/Priority:IP DSCP Mapping dialog.
 In the "Traffic Class" column, enter the desired values.
enable Switch to the privileged EXEC mode.
