Hirschmann PowerMICE User Manual

Network Load Control
180
8.4 QoS/Priority
UM Basic Configuration L3P
Release 7.1 12/2011
 Always assign DSCP priority per interface to received IP
data packets (PowerMICE, MACH 104, MACH 1040 and
MACH 4000)
 Always assign the DSCP priority to received IP data
packets globally
configure Switch to the Configuration mode.
classofservice
ip-dscp-mapping cs1 1
Assign traffic class 1 to DSCP CS1.
show classofservice ip-dscp-mapping
IP DSCP Traffic Class
------------- -------------
0(be/cs0) 2
1 2
.
.
8(cs1) 1
.
enable Switch to the privileged EXEC mode.
configure Switch to the Configuration mode.
interface 6/1
classofservice trust
ip-dscp
Switch to the interface configuration mode of
interface 6/1.
Assign the “trust ip-dscp” mode to the interface.
exit Switch to the Configuration mode.
exit Switch to the privileged EXEC mode.
show classofservice trust
6/1
Display the trust mode on interface 6/1.
Class of Service Trust Mode: IP DSCP
Non-IP Traffic Class: 2
 Select the QoS/Priority:Global dialog.
 Select trustIPDSCP in the "Trust Mode" line.
enable Switch to the privileged EXEC mode.
configure Switch to the Configuration mode.
classofservice trust ip-
dscp
Assign the "trust ip-dscp" mode globally.
exit Switch to the Configuration mode.
