Hirschmann PowerMICE User Manual

Network Load Control
UM Basic Configuration L3P
Release 7.1 12/2011
8.4 QoS/Priority
183
 Configuring Layer 3 management priority
System IP Address.............................. 10.0.1.116
Subnet Mask.................................... 255.255.255.0
Default Gateway................................ 10.0.1.200
Burned In MAC Address.......................... 00:80:63:51:7A:80
Network Configuration Protocol (BootP/DHCP).... None
DHCP Client ID (same as SNMP System Name)...... "PowerMICE-517A80"
Network Configuration Protocol HiDiscovery..... Read-Write
Management VLAN ID............................. 1
Management VLAN Priority....................... 7
Management IP-DSCP Value....................... 0(be/cs0)
Web Mode....................................... Enable
JavaScript Mode................................ Enable
 Select the QoS/Priority:Global dialog.
 In the line IP-DSCP value for management packets you enter
the IP-DSCP value with which the device sends management
packets.
enable Switch to the privileged EXEC mode.
network priority ip-dscp
cs7
Assign the value cs7 to the management priority so
that management packets with the highest priority
are handled.
exit Switch to the privileged EXEC mode.
show network Displays the management VLAN priority.
System IP Address.............................. 10.0.1.116
Subnet Mask.................................... 255.255.255.0
Default Gateway................................ 10.0.1.200
Burned In MAC Address.......................... 00:80:63:51:7A:80
Network Configuration Protocol (BootP/DHCP).... None
DHCP Client ID (same as SNMP System Name)...... "PowerMICE-517A80"
Network Configuration Protocol HiDiscovery..... Read-Write
Management VLAN ID............................. 1
Management VLAN Priority....................... 7
Management IP-DSCP Value....................... 56(cs7)
Web Mode....................................... Enable
JavaScript Mode................................ Enable
