Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 156/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
Error
Code
Description
Cause
Notice/Solution
11C1
broken wire
Force Measurement
Value
Error on value
Check the sensors and actuators. Data
Programming does not cover the operating
state. Consult Customer Service if the error
occurs again
12C1
circuit ground
13C1
circuit battery
14C1
module error
15C1
output deactivated
16C1
error +UB
17C1
data error / CAN error
18C1
timeout / CAN timeout
19C1
safety error
1AC1
parameter error
1BC1
unspecified error
1CC1
missing adjustment
Table 8 - 4
