Hirschmann qSCALE i2 Service Manual

Troubleshooting
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 34/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
3.2.4 Indicator Definitions
Indicators are located on the Central Control Unit and the Console to assist with troubleshooting basic
power and software issues.
3.2.4.1 Indicators on the cSCALE DIO Module
Visual LED Indicators are located on the top of the DIO Module
PON
Power ON
POK
Power OK
SR
Safety Relay Active
3.2.4.2 Indicator on Console Unit
Operating display: Illuminates green when the supply voltage is connected.
Operating
Display Light
