qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
4 Commissioning
4.1 Adding Wireless Sensors
If the system is equipped with wireless sensors the sensor must be added via the I/O Box Information
Screen





MAIN
WORKING
SCREEN
OP-MODE
CONFIRM
INFORMATION
SELECTION
EXTENDED
INFORMATION
DIO
INFO
AI
WIRELESS
INFO
1. Press the CAN SET
button to add
wireless sensor
Instructions
