Hirschmann qSCALE i2 Service Manual

Commissioning
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 60/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
4.2.1 Sensor Calibration Selection
Calibration for sensors is selected under the settings menu. To calibrate sensors a RCL a system
password is required. See Section 6.1 for password entry.
Information Selection Menu allows the user to view crane, sensor, and software version information and
is the starting point for diagnostic information.



MAIN
WORKING
SCREEN
OP-MODE
CONFIRM
SETUP
SENSOR
CALIBRATION
Do not calibrate!
CAN Pressure Transducers do
not need to be calibrated.
Angle Sensor Calibration
(See Section 3.1.2.2.3)
Length Sensor Calibration
(See Section 3.1.2.2.4)
Slew Sensor Calibration
(See Section 4.2.4)
Tilt Sensor Calibration
(See Section 4.2.5)
Function Keys
