Maintenance and Repair
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 74/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
5.3 qSCALE i2 Console Software Upload
This section will instruct how to upload software into a qSCALE i2 Console.
NOTE
Item needed: 2 GB or less USB flash drive.
1. Ensure the qSCALE i2 system is turned off (crane ignition key turned to the “OFF” posi-
tion)
2. Insert the USB flash drive with the software loaded into the USB port on the qSCALE i2
console (the USB port is located behind the rubber flap to the left and below the selection
knob.
3. Press and hold the top two function keys on the left side and turn the system ON (crane
ignition key turned to “on” or ACCY” position). Continue to hold for an additional 10 sec-
onds to ensure system recognizes the selection.
To Next Page
