Troubleshooting
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 51/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
3.2.12 No Console Display
If the console never displays an image, check if power is being supplied to the console. Measure the
voltage between Pin 1 (+) and Pin 3 (GND). If power is being supplied, the console must be replaced. If
power is not being supplied, trace the wiring to determine why.
