Hirschmann qSCALE i2 Service Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 95/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
6.2.4 CAN and I/O Error Codes – 11xx-1Bxx
The first two (2) digits of a CAN Bus or I/O error code signifies the type of failure.
11xx Cable Break / Lower Limit
12xx Short-Circuit to Ground
13xx Short-Circuit / Upper Limit
14xx Error on Module
15xx Disable Module
16xx Sensor Supply Voltage Error
17xx Data Error / CAN not initialized
18xx Timeout / CAN Device not responding
19xx Safety Error
1Axx Parameter Error
1Bxx Unspecified error
1Cxx Missing Adjustment
Error
Code
Description
Cause
Notice/Solution
1100
broken wire
Sensor Error:
IOLength1
Length sensor failure or
input module is defective
Check the CAN connections and wiring, the
sensor calibration, and the CAN configura-
tion. Invalid sensor swap
1200
circuit ground
1300
circuit battery
1400
module error
1500
output deactivated
1600
error +UB
1700
data error / CAN error
1800
timeout / CAN timeout
1900
safety error
1A00
parameter error
1B00
unspecified error
1C00
missing adjustment
1101
broken wire
Sensor Error: IOAngle1
Angle fault or input
module is defective
Check the CAN connections and wiring, the
sensor calibration, and the CAN configura-
tion. Invalid sensor swap
1201
circuit ground
1301
circuit battery
1401
module error
1501
output deactivated
1601
error +UB
1701
data error / CAN error
1801
timeout / CAN timeout
1901
safety error
1A01
parameter error
1B01
unspecified error
1C01
missing adjustment
