Hirschmann qSCALE i2 Service Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 90/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
6.2.3 Kinematic Error Codes – 0Axx
Error
Code
Description
Cause
Notice/Solution
0A00
Capacity utilization >=
100%
Utilization >= 100% of the Load
chart limit
Lay down the load. Only operate within al-
lowed parameters
0A01
Capacity utilization >=
110%
Utilization >= 110% of the Load
chart limit
Lay down the load. Only operate within al-
lowed parameters
0A02
Capacity utilization >=
120%
Utilization >= 120% of the Load
chart limit
Lay down the load. Only operate within al-
lowed parameters
0A03
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Lay down the load. Only operate within al-
lowed parameters
0A04
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Lay down the load. Only operate within al-
lowed parameters
0A05
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Lay down the load. Only operate within al-
lowed parameters
0A06
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Lay down the load. Only operate within al-
lowed parameters
0A07
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Lay down the load. Only operate within al-
lowed parameters
0A08
Capacity utilization >= 90%
Utilization >= 90% of the Load
chart limit
Warning: Operating close to Cut-off
0A09
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Warning: Operating close to Cut-off
0A0A
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Warning: Operating close to Cut-off
0A0B
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Warning: Operating close to Cut-off
0A0C
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Warning: Operating close to Cut-off
0A0D
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Warning: Operating close to Cut-off
0A0E
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Warning: Operating close to Cut-off
0A0F
Capacity utilization >= limit
Utilization above an application
specific Load chart limit
Warning: Operating close to Cut-off
0A10
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
0A11
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
0A12
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
0A13
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
0A14
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
0A15
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
