Hirschmann qSCALE i2 - Product Identification; Use for the Intended Purpose

General Information
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 8/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
2 General Information
This service manual is designed to assist a service or maintenance person in identifying system prob-
lem areas or malfunctions. A digital voltmeter with the capability to measure current will be required,
along with standard maintenance and service tools.
NOTE
Knowledge of how to use a voltmeter to measure both voltage and current is assumed.
NOTE
The qSCALE i2 contains several menus where queries and settings can be made only after en-
tering a password.
HINT
For system operation, refer to the console Operator’s Manual.
