Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 82/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
6.2.2 Limit Error Codes – 01xx, 02xx, 03xx, 04xx, & 05xx
The first two (2) digits of a limit error code signify the function of a given error.
01xx Global Cut
02xx Single Cut
03xx Error
04xx Warning
05xx Pre-Warning
Min radius limit un-
derrun
Booming up inside the load
chart's inner radius limit
Boom down to a valid load-chart
radius and angle
Max radius limit ex-
ceeded
Booming down outside the
load chart's outer radius
limit
Boom up to a valid load-chart radius
and angle
Booming down below the
load chart's lower angle
limit
Boom up to a valid load-chart radius
and angle
Booming up beyond the
load chart's upper angle
limit
Boom down to a valid load-chart
radius and angle
Booming down below the
load chart's lower angle
limit
Move the jib up to a load chart
permissible radius or angle
Booming up beyond the
load chart's upper angle
limit
Move the jib down to a load chart
permissible radius or angle
Booming down below the
load chart's lower angle
limit
Move the jib up to a load chart
permissible radius or angle
Booming up beyond the
load chart's upper angle
limit
Move the jib down to a load chart
permissible radius or angle
Slewing outside the Work-
ing Range
Return to the permitted Working
Range (load chart)
To Next Page
