Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 83/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
Slew angle right to large
Slewing outside the Work-
ing Range
Return to the permitted Working
Range (load chart)
Min length limit un-
derrun
Telescoping below the
Working Range
Telescope into the permitted Work-
ing Range (load chart)
Max length limit ex-
ceeded
Telescoping beyond the
Working Range
Telescope into the permitted Work-
ing Range (load chart)
Min height limit un-
derrun
Descending below the
Working Range
Move the boom into the permitted
Working Range (load chart)
Max height limit ex-
ceeded
Elevating above the Work-
ing Range
Move the boom into the permitted
Working Range (load chart)
Min wind speed limit
underrun
Exceptionally Low Wind
Speed
Operation is restricted to permitted
conditions (load chart)
Max wind speed limit
exceeded
Excessively High Wind
Speed
Operation is restricted to permitted
conditions (load chart)
Min temperature limit
underrun
Excessively Low ambient
Temperature
Operation is restricted to permitted
conditions (load chart)
Max temperature limit
exceeded
Excessively High ambient
Temperature
Operation is restricted to permitted
conditions (load chart)
Min radius limit un-
derrun
Boom up within the radius
inner limit (Load-chart /
'Grey Zone' pre-warning)
Boom down to a valid load-chart
radius and angle
Max radius limit ex-
ceeded
Boom down outside the
radius outer limit (Load-
chart / 'Grey Zone' pre-
warning)
Boom up to a valid load-chart radius
and angle
