Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 84/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
Boom down within the
radius inner limit (Load-
chart / 'Grey Zone' pre-
warning)
Boom up to a valid load-chart radius
and angle
Boom up beyond the
radius outer limit (Load-
chart / 'Grey Zone' pre-
warning)
Boom down to a valid load-chart
radius and angle
Boom down within the
radius inner limit (Load-
chart / 'Grey Zone' pre-
warning)
Move the jib up to a load chart
permissible radius or angle
Boom up beyond the
radius outer limit (Load-
chart / 'Grey Zone' pre-
warning)
Move the jib down to a load chart
permissible radius or angle
Boom down within the
radius inner limit (Load-
chart / 'Grey Zone' pre-
warning)
Move the jib up to a load chart
permissible radius or angle
Boom up beyond the
radius outer limit (Load-
chart / 'Grey Zone' pre-
warning)
Move the jib down to a load chart
permissible radius or angle
Slewing outside the Work-
ing Range (Pre-warning /
'Grey Zone')
Return to the permitted Working
Range (load chart)
Slew angle right to large
Slewing outside the Work-
ing Range (Pre-warning /
'Grey Zone')
Return to the permitted Working
Range (load chart)
Min length limit un-
derrun
Retracting within the in-
nermost Working Range
limit (Pre-warning / 'Grey
Zone')
Telescope into the permitted Work-
ing Range (load chart)
Max length limit ex-
ceeded
Extending outside the
Working Range (Pre-
warning / 'Grey Zone')
Telescope into the permitted Work-
ing Range (load chart)
Min height limit un-
derrun
Descending below the
Working Range (Pre-
warning / 'Grey Zone')
Move the boom into the permitted
Working Range (load chart)
