Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 85/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
Max height limit ex-
ceeded
Elevating above the Work-
ing Range (Pre-warning /
'Grey Zone')
Move the boom into the permitted
Working Range (load chart)
Min wind speed limit
underrun
Excessively Low Wind
Speed (Pre-warning / 'Grey
Zone')
Operation is restricted to permitted
conditions (load chart)
Max wind speed limit
exceeded
Excessively High Wind
Speed (Pre-warning / 'Grey
Zone')
Operation is restricted to permitted
conditions (load chart)
Min temperature limit
underrun
Excessively Low ambient
Temperature (Pre-warning
/ 'Grey Zone')
Operation is restricted to permitted
conditions (load chart)
Max temperature limit
exceeded
Excessively High ambient
Temperature (Pre-warning
/ 'Grey Zone')
Operation is restricted to permitted
conditions (load chart)
Min radius limit un-
derrun
Booming up beyond the
inner radius limit (user
preset- HMI or external
control)
Move the Jib down to a valid radius
and angle
Max radius limit ex-
ceeded
Booming down outside the
upper radius limit (user
preset - HMI or external
control)
Boom up to a valid radius and angle
Booming down below the
lower angle limit (user
preset- HMI or external
control)
Boom up to a valid radius and angle
Booming up beyond the
upper angle limit (user
preset- HMI or external
control)
Move the Jib down to a valid radius
and angle
Booming down below the
lower angle limit (user
preset- HMI or external
control)
Move the jib up to a valid radius or
angle
Booming up beyond the
user upper angle limit (HMI
or external control)
Move the jib down to a valid radius
or angle
