Hirschmann qSCALE i2 Service Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 78/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
6.2.1 General Errors – 00xx, 1Fxx, 2xxx, & 3xxx
Error
Code
Description
Cause
Notice/Solution
0001
System started
Normal system start
Event logging message. Not an error
0002
System restarted
Normal system start instigated by Con-
figuration Tool
Event logging message. Not an error
0011
Output system version
Unknown outcome / For information
Debugging log message. Not an error
0021
Output machine infor-
mation
Unknown outcome / For information
Debugging log message. Not an error
0070
Cyclic Logger Update
Not Available
Not Available
0071
Overload Logger Update
Not Available
Not Available
0072
Invalid operating mode
Logger update
Not Available
Not Available
0073
Cyclic Logger Update
Not Available
Not Available
0081
Date set by user
Not Available
Not Available
0082
Time set by user
Not Available
Not Available
0090
Operating mode changed
Not Available
Not Available
00AA
Output debug information
Unknown outcome / For information
Debugging log message. Not an error
00FC
Controller Not Initialized
The system is waiting for the controller
to finish initializing
The error will clear when the system
finishes the initialization process
00FD
System Sleep Mode
Unknown outcome / For information
Event logging message. Not an error
00FE
System restarted after
deleting the application
Unknown outcome / For information
Event logging message. Not an error
00FF
System stopped
Normal system stop
Event logging message. Not an error
1F00
System Error
Fatal error or failure to initialize the
system
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
1F01
Timeout
Console (HMI) communications failure
Check the bus cabling or connector.
Try turning the Ignition off and on
again. Consult Customer Service if the
error occurs again
1F02
Timeout
Kinematics communications failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
1F03
Timeout
Limiter communications failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
1F04
Timeout
Datalogger communications failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
1F05
Timeout
Communications failure with external
system
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
