Hirschmann qSCALE i2 Service Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 91/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
0A16
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
0A17
Allowable load is reduced
Application specific load chart
utilization limit has been re-
duced due to environmental
conditions
Information: Loads reduced
0A1F
Load on hook without
Operating Mode
Leaving Operating Mode with
load on hook
Lower the load
0A20
Shutdown due to overload
Utilization above the Load chart
limit
Lay down the load. Only operate within al-
lowed parameters
0A21
Overload Warning
Utilization above the Load chart
limit
Warning: Operating close to Cut-off
0A22
Safety Cut
Major Cut-off or Hydraulics
Control fault. Machine operation
is unsafe
Turn the Ignition off and on again. Consult
Customer Service if the error occurs again
0A23
Speed reduction
The speed limit of the machine
movement was lowered
Information: Speed reduction
0A24
A2B switch
Load lifting prohibited. A2B
switch asserted
Lower the load
0A25
End of rope sensor
Load lowering prohibited - rope
laying switch asserted
Lift the load
0A26
High voltage detection
Over voltage detected
Do not operate the machine in the vicinity of
high-voltage equipment or cables. Activate
the Working Range limitation to exclude haz-
ardous areas
0A27
Shutdown due to overload
feedback monitoring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A28
Overload Warning feed-
back monitoring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A29
Safety cut feedback moni-
toring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A2A
Speed reduction feedback
monitoring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A2B
A2B switch feedback moni-
toring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A2C
End of rope sensor feed-
back monitoring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A2D
High voltage detection
feedback monitoring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A2E
Summary cut
Limits or Load-chart utilization
maximum exceeded
Lay down the load. Only operate within al-
lowed parameters
0A2F
Summary cut feedback
monitoring
Shutdown failure - the feedback
contact failed
Check the electrical systems and hydraulics
0A30
Setup mode 110%
EN13000 Setup mode selected
Warning: Cut-off functions may be inactive
0A31
Rigging mode
Factory Rigging-Mode selected
All monitoring disabled. No load charts are
available or the Rigging Mode is selected.
Warning: This operation mode only permits a
load up to the maximum Rigging Mode Load
0A32
System Bypass
System override is active
Warning: Load monitoring inactive
0A33
System Bypass
System override is active
(EN13000)
Warning: Load monitoring inactive
0A34
Boom up Switch
Booming Up key active
(EN13000)
Warning: Load monitoring inactive
0A35
Bypass A2B switch
A2B override is active
Warning: Load Lift not monitored
0A36
Bypass end of rope sensor
Rope-end switch override is
active
Warning: Load Descent not monitored
