Hirschmann qSCALE i2 Service Manual

Troubleshooting
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 28/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
3.1.3.3 System Event Information
When there is an error event, the Error Event Button will activate. Pressing the Error Event button will
call up the System Event Information Screen.

OR

MAIN
WORKING
SCREEN
ERROR
EVENT
OP-MODE
CONFIRM
ERROR
EVENT
If several messages of the same class are present use the dial control to change the current message.
The function key is dark blue when that screen is activated.
View Errors of Class 1
View Errors of Class 2
View Errors of Class 3
View Errors of Class 4
View Errors of Class 5
View Errors of All Classes
