Troubleshooting
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 30/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
THE DISPLAYED SLEWING DOES NOT MATCH THE ACTUAL SLEWING ANGLE
Refer to Section 3.2.10 to troubleshoot possible problems with the slew angle measurement.
THE DISPLAYED TILT DOES NOT MATCH THE ACTUAL TILT
Start in Section 3.2.11 to troubleshoot possible problems with the tilt measurement
THE CONSOLE DISPLAY IS BLANK
If the console does not show any sign at all (no lights, no buzzer, and no display), the problem is in the
wiring between console and central unit, or the console itself has a problem. Refer to Section 3.2.12 for
further troubleshooting.
