Commissioning
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 67/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
5. Slew the boom clockwise at least 5° (max-
imum 80°)
6. Press the SET button to confirm
this is completed.
7. It must be confirmed a second time that
the boom is moved to the front of the ma-
chine.
8. Press the SET button to confirm
this is completed.
