Operating Mode Selection
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 12/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
X xxxx
In case of a malfunction or an operating error, a corresponding
system event code "# ####" appears on the display. The system
event codes and what they mean can be displayed on the console
(see Section 3.2), and are explained in the error codes table (see
Section 5.2). See Section 3.1.2 for more information on warning
symbols.
The device is only ready for operation after all faults have been
rectified and no error codes are displayed.
If the console is not started as described, please contact the near-
est service department.
System Malfunction
System Event Code
Warning Symbols
Operating Mode
(see Section 2.2)
