Limit Error Codes
The first two (2) digits of a limit error code signify the function of a given error.
01xx Global Cut
02xx Single Cut
03xx Error
04xx Warning
05xx Pre-Warning
Min radius limit underrun
Max radius limit exceeded
Slew angle right to large
Min length limit underrun
Max length limit exceeded
Min height limit underrun
Max height limit exceeded
Min wind speed limit underrun
Max wind speed limit exceeded
Slew angle right to large
Min temperature limit underrun
Min length limit underrun
Max temperature limit exceeded
Max length limit exceeded
Min radius limit underrun
Min height limit underrun
Max radius limit exceeded
Max height limit exceeded
Min wind speed limit underrun
Max wind speed limit exceeded
Min temperature limit underrun
Max temperature limit exceeded
Min radius limit underrun
Max radius limit exceeded
Slew angle right to large
Min length limit underrun
Max length limit exceeded
Min height limit underrun
Max height limit exceeded
Min wind speed limit underrun
Max wind speed limit exceeded
Slew angle right to large
Min temperature limit underrun
Min length limit underrun
Max temperature limit exceeded
Max length limit exceeded
Superstructure Inclination
Min height limit underrun
Min load limit on outrigger underrun front left
Max height limit exceeded
Max load limit on outrigger reached front left
Min wind speed limit underrun
Min load limit on outrigger underrun front center
Max wind speed limit exceeded
Max load limit on outrigger reached front center
Min temperature limit underrun
Min load limit on outrigger underrun front right
Max temperature limit exceeded
Max load limit on outrigger reached front right
Min radius limit underrun
Min load limit on outrigger underrun rear left
Max radius limit exceeded
Max load limit on outrigger reached rear left
Min load limit on outrigger underrun rear center
Max load limit on outrigger reached rear center
Min load limit on outrigger underrun rear right
Max load limit on outrigger reached rear right
