Hirschmann qSCALE i2 User Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 52/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
Kinematic Error Codes
Error
Code
Description
Error
Code
Description
0A00
Capacity utilization >= 100%
0A3D
Jib up motion monitoring
0A01
Capacity utilization >= 110%
0A3E
Jib down motion disabled
0A02
Capacity utilization >= 120%
0A3F
Jib down motion monitoring
0A03
Capacity utilization >= limit
0A40
Boom up movement disabled
0A04
Capacity utilization >= limit
0A41
Boom up movement monitoring
0A05
Capacity utilization >= limit
0A42
Boom down disabled
0A06
Capacity utilization >= limit
0A43
Boom down movement monitoring
0A07
Capacity utilization >= limit
0A44
Motion out disabled
0A08
Capacity utilization >= 90%
0A45
Motion out motion monitoring
0A09
Capacity utilization >= limit
0A46
Motion in disabled
0A0A
Capacity utilization >= limit
0A47
Motion in motion monitoring
0A0B
Capacity utilization >= limit
0A48
Motion left disabled
0A0C
Capacity utilization >= limit
0A49
Motion left motion monitoring
0A0D
Capacity utilization >= limit
0A4A
Motion right disabled
0A0E
Capacity utilization >= limit
0A4B
Motion right motion monitoring
0A0F
Capacity utilization >= limit
0A4C
Motion load up deactivated
0A10
Allowable load is reduced
0A4D
Motion load up motion monitoring
0A11
Allowable load is reduced
0A4E
Motion load down deactivated
0A12
Allowable load is reduced
0A4F
Motion load down motion monitoring
0A13
Allowable load is reduced
0A50
Invalid operation mode
0A14
Allowable load is reduced
0A51
Invalid telescope mode
0A15
Allowable load is reduced
0A52
Invalid reeving
0A16
Allowable load is reduced
0A53
Invalid winch configuration
0A17
Allowable load is reduced
0A54
Invalid Outrigger
0A1F
Load on hook without Operating Mode
0A55
Invalid bolting
0A20
Shutdown due to overload
0A56
Invalid counterweight
0A21
Overload Warning
0A57
Invalid winch configuration
0A22
Safety Cut
0A58
Invalid main boom configuration
0A23
Speed reduction
0A59
Invalid criteria
0A24
A2B switch
0A5A
Operating under a load
0A25
End of rope sensor
0A5B
Invalid capacity utilization
0A26
High voltage detection
0A61
Invalid feasible operation mode
0A27
Shutdown due to overload feedback monitoring
0A62
Invalid feasible operation mode
0A28
Overload Warning feedback monitoring
0A63
Invalid feasible operation mode
0A29
Safety cut feedback monitoring
0A64
Invalid feasible operation mode
0A2A
Speed reduction feedback monitoring
0A65
Invalid feasible operation mode
0A2B
A2B switch feedback monitoring
0A66
Invalid feasible operation mode
0A2C
End of rope sensor feedback monitoring
0A67
Invalid feasible operation mode
0A2D
High voltage detection feedback monitoring
0A68
Invalid feasible operation mode
0A2E
Summary cut
0A6A
Invalid value
0A2F
Summary cut feedback monitoring
0A6B
Invalid value
0A30
Setup mode 110%
0A6C
Invalid value
0A31
Rigging mode
0A70
Redundancy error
0A32
System Bypass
0A71
Redundancy error
0A33
System Bypass
0A72
Redundancy error
0A34
Boom up Switch
0A73
Redundancy error
0A35
Bypass A2B switch
0A74
Redundancy error
0A36
Bypass end of rope sensor
0A75
Redundancy error
0A37
System Bypass
0A76
Redundancy error
0A38
Bypass high voltage detection
0A77
Redundancy error
0A39
Bypass end of outrigger cut
0A7F
Redundancy error
0A3C
Jib up motion disabled
0AA0
Outrigger load detection
