Hirschmann qSCALE i2 User Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 53/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
CAN Error Codes
The first two (2) digits of a CAN Bus or I/O error code signifies the type of failure.
11xx Cable Break / Lower Limit
12xx Short-Circuit to Ground
13xx Short-Circuit / Upper Limit
14xx Error on Module
15xx Disable Module
16xx Sensor Supply Voltage Error
17xx Data Error / CAN not initialized
18xx Timeout / CAN Device not responding
19xx Safety Error
1Axx Parameter Error
1Bxx Unspecified error
1Cxx Missing Adjustment
Error
Code
Description
Error
Code
Description
xx93
Actuator Error: IOAuditAlert
xx26
Sensor Error: IOForce7
xx67
Actuator Error: IOBoomDown
xx27
Sensor Error: IOForce8
xx66
Actuator Error: IOBoomUp
xx96
Sensor Error: IOHardWireSW
xx61
Actuator Error: IOCut
xx38
Sensor Error: IOIncX1
xx7B
Actuator Error: IODown
xx3A
Sensor Error: IOIncX2
xx86
Actuator Error: IOEnableA2B
xx39
Sensor Error: IOIncY1
xx87
Actuator Error: IOEnableA2B
xx3B
Sensor Error: IOIncY2
xx90
Actuator Error: IOEnableHDU
xx18
Sensor Error: IOInput1
xx98
Actuator Error: IOEnableOutrigger
xx19
Sensor Error: IOInput2
xx88
Actuator Error: IOEnableThirdWrapRow
xx1A
Sensor Error: IOInput3
xx89
Actuator Error: IOEnableThirdWrapRow
xx1B
Sensor Error: IOInput4
xx6F
Actuator Error: IOHorn
xx1C
Sensor Error: IOInput5
xx6C
Actuator Error: IOLampGreen
xx1D
Sensor Error: IOInput6
xx6E
Actuator Error: IOLampRed
xx1E
Sensor Error: IOInput7
xx92
Actuator Error: IOLampSingle
xx1F
Sensor Error: IOInput8
xx6D
Actuator Error: IOLampYellow
xx00
Sensor Error: IOLength1
xx78
Actuator Error: IOLeft
xx04
Sensor Error: IOLength2
xx94
Actuator Error: IOLoadWarning
xx08
Sensor Error: IOLength3
xx7E
Actuator Error: IOOutput1
xx0C
Sensor Error: IOLength4
xx7F
Actuator Error: IOOutput2
xx42
Sensor Error: IOLuffUp1
xx80
Actuator Error: IOOutput3
xx43
Sensor Error: IOLuffUp2
xx81
Actuator Error: IOOutput4
xx2C
Sensor Error: IOMAngle1
xx82
Actuator Error: IOOutput5
xx2D
Sensor Error: IOMAngle2
xx83
Actuator Error: IOOutput6
xx2E
Sensor Error: IOMAngle3
xx84
Actuator Error: IOOutput7
xx2F
Sensor Error: IOMAngle4
xx85
Actuator Error: IOOutput8
xx3C
Sensor Error: IOMaxA2B1
xx63
Actuator Error: IORigging
xx3D
Sensor Error: IOMaxA2B2
xx79
Actuator Error: IORight
xx3E
Sensor Error: IOMinTW1
xx60
Actuator Error: IOSafety
xx3F
Sensor Error: IOMinTW2
xx74
Actuator Error: IOSafety1
xx30
Sensor Error: IOOutrigger1
xx75
Actuator Error: IOSafety2
xx31
Sensor Error: IOOutrigger2
xx76
Actuator Error: IOSafety3
xx32
Sensor Error: IOOutrigger3
xx77
Actuator Error: IOSafety4
xx33
Sensor Error: IOOutrigger4
xx68
Actuator Error: IOSlewLeft
xx10
Sensor Error: IOPinning1
xx69
Actuator Error: IOSlewRight
xx11
Sensor Error: IOPinning2
xx62
Actuator Error: IOSpeed
xx12
Sensor Error: IOPinning3
xx64
Actuator Error: IOTeleIn
xx13
Sensor Error: IOPinning4
xx65
Actuator Error: IOTeleOut
xx14
Sensor Error: IOPinning5
xx7A
Actuator Error: IOUp
xx15
Sensor Error: IOPinning6
xx6B
Actuator Error: IOWinchDown
xx16
Sensor Error: IOPinning7
xx6A
Actuator Error: IOWinchUp
xx17
Sensor Error: IOPinning8
xx9F
Actuator Error: unspecified
xx02
Sensor Error: IOPiston1
xxA4
Boom Angle
xx06
Sensor Error: IOPiston2
xxA5
Boom Length
xx0A
Sensor Error: IOPiston3
