Hirschmann qSCALE i2 User Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 54/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
Error
Code
Description
Error
Code
Description
xxA9
Capacity
xx0E
Sensor Error: IOPiston4
xxA8
Environment Temperature
xx03
Sensor Error: IORod1
xxBE
Force Measurement Value
xx07
Sensor Error: IORod2
xxBF
Force Measurement Value
xx0B
Sensor Error: IORod3
xxC0
Force Measurement Value
xx0F
Sensor Error: IORod4
xxC1
Force Measurement Value
xx70
Sensor Error: IOSafety1C
xxA2
Height Value
xx71
Sensor Error: IOSafety2C
xxB6
Jib angle measurement
xx72
Sensor Error: IOSafety3C
xxB7
Jib relative angle measurement
xx73
Sensor Error: IOSafety4C
xxB9
Length measurement outrigger front center
xx40
Sensor Error: IOSetup1
xxB8
Length measurement outrigger front left
xx41
Sensor Error: IOSetup2
xxBA
Length measurement outrigger front right
xx28
Sensor Error: IOSlew1
xxBC
Length measurement outrigger rear center
xx29
Sensor Error: IOSlew2
xxBB
Length measurement outrigger rear left
xx2A
Sensor Error: IOSlew3
xxBD
Length measurement outrigger rear right
xx2B
Sensor Error: IOSlew4
xxA0
Length Value
xx48
Sensor Error: IOStick1
xxAA
Load
xx49
Sensor Error: IOStick2
xxB1
Load measurement outrigger front center
xx46
Sensor Error: IOStopp1
xxB0
Load measurement outrigger front left
xx47
Sensor Error: IOStopp2
xxB2
Load measurement outrigger front right
xx50
Sensor Error: IOTele1
xxB4
Load measurement outrigger rear center
xx51
Sensor Error: IOTele2
xxB3
Load measurement outrigger rear left
xx52
Sensor Error: IOTele3
xxB5
Load measurement outrigger rear right
xx53
Sensor Error: IOTele4
xxAC
Piston Pressure Cyl. 1
xx54
Sensor Error: IOTele5
xxAE
Piston Pressure Cyl. 2
xx55
Sensor Error: IOTele6
xxA1
Radius Value
xx56
Sensor Error: IOTele7
xxAD
Rod Pressure Cyl. 1
xx57
Sensor Error: IOTele8
xxAF
Rod Pressure Cyl. 2
xx58
Sensor Error: IOTeleSw1
xx01
Sensor Error: IOAngle1
xx59
Sensor Error: IOTeleSw2
xx05
Sensor Error: IOAngle2
xx5A
Sensor Error: IOTeleSw3
xx09
Sensor Error: IOAngle3
xx5B
Sensor Error: IOTeleSw4
xx0D
Sensor Error: IOAngle4
xx5C
Sensor Error: IOTeleSw5
xx95
Sensor Error: IOBridgeSW
xx5D
Sensor Error: IOTeleSw6
xx4C
Sensor Error: IOBypA2B1
xx5E
Sensor Error: IOTeleSw7
xx4D
Sensor Error: IOBypA2B2
xx5F
Sensor Error: IOTeleSw8
xx99
Sensor Error: IOBypOutrigger
xx7C
Sensor Error: IOTemp1
xx4E
Sensor Error: IOBypTW1
xx7D
Sensor Error: IOTemp2
xx4F
Sensor Error: IOBypTW2
xx4A
Sensor Error: IOVoltage1
xx91
Sensor Error: IOBypVoltage
xx4B
Sensor Error: IOVoltage2
xx97
Sensor Error: IOCancelHorn
xx36
Sensor Error: IOWeight1
xx44
Sensor Error: IOCutByp1
xx37
Sensor Error: IOWeight2
xx45
Sensor Error: IOCutByp2
xx34
Sensor Error: IOWind1
xx20
Sensor Error: IOForce1
xx35
Sensor Error: IOWind2
xx21
Sensor Error: IOForce2
xxA3
Slew Angle
xx22
Sensor Error: IOForce3
xxA6
Superstructure Inclination X
xx23
Sensor Error: IOForce4
xxA7
Superstructure Inclination Y
xx24
Sensor Error: IOForce5
xxAB
Wind Speed
xx25
Sensor Error: IOForce6
