Specifications
2-7
Engine Specifications
Item Metric Standard Service Wear Limit
Warp limit *
Cylinder
Bore size
Measuring point *
Camshaft
Drive method
Cam dimensions
Intake
“A”
“B”
Exhaust
“A”
“B”
91.016 – 91.030mm (3.544- 3.584 in)
50 mm (1.97 in)
31.95 ~ 32.11mm (1.258~ 1.264 in)
25.95 ~ 26.05mm (1.022 ~ 1.026in)
32.14~ 32.30mm (1.2654~ 1.2717in)
25.95~26.05 (1.2165~1.0256in)
0.03 mm(0.0012 in)
