Periodic Maintenance
3-10
Checking the coolant level
The reservoir bottle can be seen behind
the right front tire.
The level should be kept between the
minimum (b) and the maximum (a) level
bars on the bottle.
Use a Ethylene Glycol type antifreeze
color green, at a 50/50 diluted mix and add
as needed.
Changing the coolant
Remove the driver’s seat, passenger’s
seat, and the center console.
Remove the roll-over protection system.
Remove the hood assembly.
Remove the reservoir cap (1) disconnect
the coolant reservoir hose (2).
Note:
Adding water instead of coolant lowers
the antifreeze content. A 50/50 mix is
necessary for summer cooling of the
motor and for winter antifreeze up
conditions.
Drain the coolant from the reservoir.
Connect the reservoir hose.
Remove the coolant drain bolt (water
pump) (1) along with the copper sealing
washer.
Remove the radiator cap (1)
