10
1.5 Network Bridge Function
1. Network Function
This projector is eTuipped with the NETWORK %RID*E function to perform
mutual conYersion of a network protocol and a serial interface.
%y making use of the NETWORK %RID*E function, a computer connected to the
projector Yia wireless or wired /AN is able to control an external deYice Yia
RS-232C communication using the projector as a network deYice.
RS-232C
RS-232C cable
CONTROL port
LAN port
External deYice
Wired /AN
/AN cable
Computer
Protocol change
TCP/IP data Serial data
USB TYPE A port
Wireless adapter)
Wireless
/AN
