Hitachi F-4700 - 1.5 Assembly Procedures

1 - 9
1.5 Assembly
WARNING
Contact with the power supply voltage could cause an electric shock,
resulting in fatal or serious injury. Before starting assembly, make sure that
the power switch of the spectrophotometer main unit is OFF and the power
cord is disconnected.
1.5.1 Attachment of Xenon Lamp
(1) Detach the cover from the light source compartment on the left side of the instrument.
Fig. 1-7 Light Source Compartment Cover
Remove these two screws.
